GATE ARRANGEMENT
It is necessary to make controls on the gate to make sure the application of FORTE automation can be possible. Make sure that:
the gate fixed and moving parts have a strong and crush-proof structure;
•
the length of each leaf is not over 3m (FORTE 40), 5m (FORTE 60);
•
the weight of each leaf is not over 300Kg (FORTE 40), 500Kg ( FORTE 60);
•
the hinges are hardly anchored and are able to support the torque of the operator; they do not have irregular movements
•
and/or any friction during the whole movement of the leaf;
the stops of the leaf are fixed to the ground (Fig. 2).
•
NOTICE: THE OPERATOR MUST BE INSTALLED WITH THE MOTOR FACING UPWARD (FIG. 1)
INSTALLATION OF THE OPERATORS
Fix the holed mounting plate to the post using screws as shown in Fig 3. The plate must be positioned perfectly horizontal and
perpendicular to the post. Weld the back bracket to the plate (Fig 4) following the dimensions shown in table (page 2). If it is necessary,
cut the bracket without going over the minimum limit of 60mm (Fig 6).
WARNING: Turn the shaft up to its max. extension, afterwards turn it about at least half turn into the
Note: After installation, in opening, leave minimum 15 mm of working stroke, to avoid that the operator goes into mechanical lock (if
necessary install the stops on the ground or the optional special mechanical stops for FORTE). Attach the front bracket to the extremity
of the shaft (Fig 10) Close the gate. Drill a hole into the gate (Fig 12) to be able to attach the front bracket with the supplied bolts being
careful to place the operator perfectly horizontal (Fig 13).
NOTE:
IF IT IS NOT POSSIBLE TO ATTACH THE FRONT BRACKET WITH THE BOLTS, WELD IT TO THE GATE (FIG
14), BEING CAREFUL TO PROTECT THE SHAFT FROM WELDING WASTE.
Release the arm (see paragraph RELEASING SYSTEM OF THE OPERATOR) Remove the pull tongue from the shaft-cover (Fig 16) and mount
it on the operator through the two tie-rods without excessively tightening the two cover-nuts (Fig 17).
CONNECTIONS (FIG. 15)
NOTICE: FORTE OPERATOR IS NOT PROVIDED WITH MECHANICAL TORQUE REGULATION. THE CONTROL
BOARD MUST BE PROVIDED WITH ELECTRONIC TORQUE REGULATION (UNLESS PRESENCE DETECTORS
ARE INSTALLED) TO INSTALL IT IN CONFORMITY WITH THE DIRETTIVA EN12453 AND EN12445.
When inserting the lids (1) make sure that the gaskets (2) are correctly installed.
RELEASING SYSTEM OF THE OPERATOR
To release the operator follow the instruction below
put the red T-shaped release key into the hexagonal hole as in Fig. 18
•
turn the release key of 90° toward right or left until it stops without forcing (Fig. 19).
•
To lock the actuator again bring the line in the horizontal position through the release key (Fig. 18) and move the leaf manually
•
until the clutch of the automation.
RISK EXAMINATION
The points pointed by arrows in Fig. 20 are potentially dangerous. The installer must take a thorough risk examination to prevent
crushing, conveying, cutting, grappling, trapping so as to guarantee a safe installation for people, things and animals (Laws in force in
the country where installation has been made).
opposit direction (screw it) see Fig. 8 and 9.
