Contatti e LED – Contacts and LED – Contactos y LED – Contacts et LED
IT
Morsetti
Tipo
1-2
N.A.
START (Sequenziale, APRE/STOP/CHIUDE/STOP)
3-2
N.A.
PEDONALE
4-6
N.C.
FOTOCELLULA/COSTA MECCANICA (Chiusura) *
5-6
N.C.
FOTOCELLULA (Apertura/Chiusura) *
7-6
N.C.
STOP *
9-8
N.C.
FINE CORSA APERTURA
10-8
N.C.
FINE CORSA CHIUSURA
11-12
24Vac
Alimentazione accessori 24Vac 250mA MAX
13-14-15 110/230V MOTORE (13 – 14 FASI, 15 COMUNE) **
16-18
110/230V LAMPEGGIANTE
17-18
110/230V LUCE DI CORTESIA (Contatto puro)
19-20
110/230V INGRESSO LINEA 110/230 Vac
21-22
----
ANTENNA (21 Calza, 22 Segnale)
* Se non utilizzato ponticellare (COMUNE 2-6-8)
** Condensatore tra le due fasi (13 – 14)
ES
Borne s
Ti po
1-2
N.A.
START (Secuencial, ABRE/STOP/CIERRA/STOP)
3-2
N.A.
PEATONAL
4-6
N.C.
BANDAS/FOTOCÉLULA (Solo en apertura) *
5-6
N.C.
FOTOCÉLULA (Apertura y cierre)
7-6
N.C.
STOP *
9-8
N.C.
FIN DE CARRERA APERTURA *
10-8
N.C.
FIN DE CARRERA CIERRE *
11-12
24Vac
Alimentaciòn ACCESORIOS (24Vac 250mA MAX)
13-14-15 110/230 V Alimentaciòn MOTOR (13-14 fases, 15 comùn) **
16-18
111/230 V BALIZA
17-18
112/230 V LUZ DE CORTESÌA (Contàcto puro)
19-20
230Vac
INGRESO LINEA 110/230 Vac
21-22
----
Conexiòn Antena (21 malla – 22 señal)
* Si non utilizado, puentear con comùn (2 - 6 - 8)
** Capacitor entre las dos fases (13 - 14)
IT
L1
LED STATO
L2
LED RADIO
L3
LED PROG. PERCORSO
L4
LED START
L5
LED PEDONALE
L6
LED FOTOCELLULA
L7
LED FINECORSA APERTURA ON su impulso contatto START
L8
LED FINECORSA CHIUSURA ON su finecorsa ap. non attivato
L7+L8 LED STOP
ES
L1
LED ESTADO
L2
LED RADIO
L3
LED PROG. RECORRIDO DESTELLA en programaciòn
L4
LED START
L5
LED PEATONAL
L6
LED FOTOCELDA
L7
LED F.C. APERTURA
L8
LED F.C. CIERRE
L7+L8 LED STOP
Descrizi one
Descri pci ón
ON con centrale alimentata
ON su accesso memoria radiocomandi
ON lampeggiante su programmazione
ON su impulso (radiocomando o sel.)
ON su impulso apertura pedonale
ON su allineamento fotocellule
ON su stop non attivato
ON con central encendida
ON durante programaciòn controles
ON con pulso START o control remoto
ON en PEATONAL o control r. peatonal
LED FOTOCELDA
LED FINAL DE CARRERA CIERRE
LED FINAL DE CARRERA APERTURA
LED STOP
EN
Tipo
N.A.
START (Sequential, OPEN/STOP/CLOSE/STOP)
N.A.
PEDESTRIAN
N.C.
EDGE/PHOTOCELL (Closing) *
N.C.
PHOTOCELL – (Opening-Closing) *
N.C.
STOP *
N.C.
OPENING LIMIT SWITCH
N.C.
CLOSING LIMIT SWITCH
24Vac
ACCESSORIES Power (24Vac 250mA)
110/230 V ENGINE Power (13-14 phases, 15 common) **
111/230 V FLASHING power
112/230 V COURTESY LIGHT Power
230Vac
POWER INPUT 110/230 Vac
----
External antenna connection (21 braid-22 signal)
* If not used, jumper with Common (2 - 6 – 8)
** Capacitor between the two phases (13 – 14)
FR
Genre
N.A.
START(séquentielle, OUVRE/STOP/FERME/STOP)
N.A.
PIETON
N.C.
BARRE/CELLULE – OUVERTURE *
N.C.
CELLULE – FERMETURE *
N.C.
STOP *
N.C.
FIN DE COURSE OUVERTURE *
N.C.
FIN DE COURSE FERMETURE *
24Vac
Accessoires Alimentation 24Vac 250mA MAX
110/230V MOTEUR (13-14 PHASES, 15 COMMON) **
111/230V CLIGNOTANT
112/230V LUMIERE DE COURTOISE
230Vac
ENTRÉE 110/230 Vac
----
ANTENNA (21 Bas – 22 signal)
* En cas d'inutilisation cavalier - COMMON (2-6-8)
** Condensateur entre les deux phases (13 - 14)
EN
L1
LED STATUS
L2
LED RADIO
L3
LED PROG. RIME
L4
LED START
L5
LED PEDESTRIAN
L6
LED PHOTOCELL
L7
LED LIMIT SWITCH OPEN
L8
LED LIMIT SWITCH CLOSE
L7+L8 LED STOP
FR
L1
LED STATUS
L2
LED RADIO
L3
LED PROG. TEMPS
L4
LED START
L5
LED PIETON
L6
LED PHOTOCELLULE
L7
LED FC OUVERTURE
L8
LED FC FERMETURE
L7+L8 LED STOP
Descri ption
Descrizione
ON with General power up
ON on radio access memory
FLASHING on programming
ON on start
ON on pedestrian pulse
ON photocells aligned
ON on opening limit switch
ON on closing limit switch
ON on stop
ON platine alimentée
ON accès memoire radio
CLIGNOTE: en programmation
ON avec un Start
ON avec impulse pieton
On photocellules alignées
ON sur fc ouverture
ON sur fc fermeture
ON sur stop
