MULTICODE SINGLE
KEY CUTTING MACHINE
10.5 CUTTING INFORMATION (FILE)
Once the program is connected to the MULTICODE SINGLE in the JMAKeyPro program, we have access to see the
technical information for cutting the key. If there is no link with the MULTICODE SINGLE machine, this information is
not accessible.
Toothed key files Keys cut with the horizontal tool and where we have the MP1 jaw with four sides, the possibility of
changing to other jaws, personalization of special key profiles.
10.5.1 TOOTHED KEY FILES
When searching for a key (AZBE) or a biting code (e.g. 15000J) we can see its mechanical data by clicking on top of
the file (in this case 507).
When clicking on the file we enter the file screen where we can see the technical data of the key and it will tell us
how to attach the key, (side of the jaw, limit...).
