Image of a clamp with the numbering of the slots to make the limits. (Fig. 16)
All the necessary information about attaching the key from the JMAKeyPro software in the tablet will appear when
the key code is introduced.
3.1.2 SPECIAL CLAMPS
• MP1-RS8
Clamp RS8 has 4 sides to duplicate the following key models (Fig. 1):
• Side 1: Key with normal bit (Standard).
• Side 2: RS8 model key.
• Side 3: Key with guide on the bottom.
• Side 4: Key with guide on the top.
60
Side 1: Limits 1, 2, 3.
Side 2: Limits 1, 2.
Side 3: Limits 1, 2.
Side 4: Limits 1, 2.
GUIDE ON THE
ESTANDAR
FIG. 16
TOP
GUIDE ON
THE
BOTTOM
RS8
