7. Move the seat with the seat box forwards and secure it against falling backwards.
8. Fit the air connection (1) on the seat and the electrical plug (2) on the seat from the hose/cable
harness adapter.
9. Fit the seat connection's electrical plug (3) into the vehicle connection in the adapter bridge.
10. Fit the EPS cable's electrical plug (4) into the vehicle connection in the adapter bridge.
Important note:
The electrical connections for the seat's power supply (plus / minus) must be established by
specialist. See the circuit diagram in Chapter 5.
Ensure that the cable and the hose cannot crisscross during the installation and the seat
adjustment process.
U
11. Use the end clip (1) to secure the EPS cable to the air spring-cap
12. Fold the seat back.
13. Activate the express down mechanism.
14. Start the engine in order to build up the air pressure needed for the remaining part of the installation.
RECARO Automotive Seating
1
2
4
3
K0300
1 Air connection
2 Electric plug
3 Seat's electrical connection
4 Electrical connection for EPS cable
1 End clip
