1. Introduction

Installed between the mains and the load, the Uninterruptible Power Supply (UPS) protects
electronically sensitive equipment against power disturbances and failures.
The UPS works on the Digital On-Line principle. This means that the connected equipment
is powered from the mains after passing through a voltage stabilizer and diverse filters. This
reduces disturbance from the mains which in turn increases the safety level of equipment
operation (PCs, servers, distributed systems, etc.).
In the event of a mains failure, and thanks to the Digital On-Line technology, the built-in,
maintenance-free battery assumes the uninterrupted supply of energy to the connected
equipment using a sinusoidal waveform. The energy from the UPS enables the system to
keep working until the mains power returns or, in the event of a prolonged outage, the UPS
UK
will inform the user when all processes must be terminated and the system shut down.
The UPS indicates through acoustic (buzzer) and optical (LED) alarms that a mains failure
has occurred or persists in order to end all tasks and shut down the system accordingly.
The most reliable way is to use the monitoring software associated with the UPS. This soft-
ware permanently indicates the expected autonomy of the battery prior to and during a fai-
lure in the mains voltage. In addition, the process for closing down the system can be pro-
grammed to take place automatically. The applications, operating system and the computer
hardware can be programmed to close down automatically and to notify the server's regis-
tered users in the event of a prolonged network failure. For more detailed information on this
monitoring software, please consult the literature available on CHLORIDE's Connectivity
Solutions.
When the mains power returns, the UPS starts working again automatically as long as the
Stand-By time limit has not been exceeded (can be programmed using the monitoring soft-
ware).
In the event of an overload or internal failure, the load will be transferred automatically to the
power network by means of an automatic by-pass. Once the load is reduced or the internal
failure disappears, the UPS unit will automatically resume working in the normal operating
mode.
These instructions contain all of the information necessary for the installation and operation
of the UPS.
