• Instrument transportation

The instrument is always supplied with the appropriate carrying case or soft case in eco-friendly material.
Use the original accessorises only, to transport the instrument. If you need to buy it again, contact your local
distributor. The interior of the classic case or the IP 67 one is shaped to be able to house the instrument and
the sensors still connected.

• Key functions

Button Pression Function
Press to turn the device on or off.
Short
In measure mode, press to scroll through the different parameters:
Short
pH  mV  ISE  ORP  Cond  TDS  Sal  Res  DO%  DOmg/L  mbar  multi view
In Setup move the cursor to the right column.
Long-press In measure mode keep pressed to access the full screen view.
(3s)
In calibration, setup and memory recall mode, press to return to measure mode.
Short
Long-press In measure mode, press to start the calibration.
(3s)
In measure mode, press to enter the setup.
Short
In the setup menus, press to select the desired program and / or value.
During calibration, press to confirm the value.
In the setup and subset menus press to scroll.
In the setup submenus, press to change the value.
In memory recall mode, press to scroll through the saved values.
In MTC and custom calibration mode, press to change the value.
Short
end the recording (Automatic Data Logger).
In measure mode, keep one of the two keys pressed to change the temperature in
MTC mode (manual compensation, without probe). When the value starts to flash,
Long-press
the user can change the temperature value by entering the correct one and
(3s)
confirming with
Further key functions:
• When the Sleep mode is active (selectable from 1 to 20 minutes)) press any key to reactivate the
brightness of the display.
Only at this point do the keys regain their function.
When in measure mode you are in full screen mode (activated by long pressing the button
•
press any key to exit and return to the standard display.

• Inputs / Outputs connections

Use original accessories guaranteed by the manufacturer only.
If necessary, contact your local distributor. The BNC connectors are protected by a plastic cap. Remove the
cap before connecting the probes.
UM ReVio EN rev.0 04.06.2020
: In measure mode, press to save the data (manual Data Logger) or start and
: In measure mode, press to recall the saved data.
.
