If there are sharp bends near the fittings, it is advisable to tie the tube to a suitable support so as not
6.
to stress the fitting with unnecessary forces and to extend the lifespan of the Product.
Using curved supports
If it is necessary to make a curve in a particular position or if it is not possible to tie the pipe to any
support, use of a curved support (optional - picture 17) is recommended for diameters of 1/2" and
5/8".
Slightly cut into the insulation with a cutter or scissors (not included - picture 18);
1.
Caution! Do not damage FastPipe
Open the insulation along the incision (picture 19);
2.
Place near one of the ends of the curved support and insert it by applying light pressure
3.
FastPipe
®
(picture 20);
Let travel along the rest of the curve and then insert it on the support, exerting slight
4. FastPipe
®
pressure (pictures
21
It is recommended to insert the pipe on the support with a longitudinal force along the tube
(picture
23).
Wrap the insulation around
5.
Wrap the insulation with the anti-UV protective tape provided to restore the seal of the insulation
6.
(picture 25).
Inserting and crimping the fitting:
Caution: a electric screwdriver (not included) is required for this operation.
Wear the supplied SuperGrip gloves;
1.
Install the bit with the appropriate diameter on the screwdriver;
2.
Move the insulation away to make enough space to grasp the end of
3.
(picture 26);
Grasp firmly, as shown in picture 27;
4.
FastPipe
®
Insert the calibrator (or the calibration cross) of the correct diameter into the tube, and rotate the
5.
tool various times (picture 28);
The calibrator must be inserted as far as it will go.
The calibration operation takes at least 10 seconds.
Set the screwdriver to minimum speed;
6.
The screwdriver must be operated at minimum speed to ensure maximum available torque.
Fit the nut and the insert onto the tool (picture 29);
7.
Place the bushing on
8.
Hold firmly and screw the insert in until it can go no further (picture 31);
9.
FastPipe
®
Caution! Do not continue screwing the insert after it has come to a stop on the bushing as
this may damage FastPipe
Unhook the fitting from the bit by unscrewing the nut;
10.
After installing the correct diameter die on the crimping tool, proceed with crimping. This operation
11.
is described in the paragraph "Crimping the fitting" on page 22.
FastPipe
with excessively deep incisions.
®
and 22);
again (picture 24);
FastPipe
®
(picture 30);
FastPipe
®
.
®
