Brudden movement EDGE PECTORAL Manual De Montaje página 56

ASSEMBLY
STEP 4 - ASSEMBLY OF THE COWLING BRACKET
16 NAME
Head Screw Aba. Hex Int.
M8X20
J NAME
Lower cowling bracket
K NAME
Upper cowling bracket
Tools
Allen 5 mm
Qty
6x
J
16
21
Figure 4-1
K
16
Figure 4-2
K
16
