TEMPERATURE MANAGEMENT SYSTEM
Appendix B: Symbols
The A S Temperature Management System Control module bears the following symbols:
®
rctic un
1
2
50°C
-30°C
95
05
10
For the safe and effective use of this device, the operator must consult the accompanying
documents prior to use.
Identifies European Representative.
This symbol adjacent to the patient connections means that the thermal probe connection is a
"Defibrillator-Proof, Type BF Applied Part", per standard IEC 60601-1 and affords the degree of
patient protection defined in that standard for this type of applied part.
Models of the A S Temperature Management System Model 5000 that bear the ETL
®
rctic un
Monogram have been Certified for Safety by ETL Intertek in accordance with standards CAN/
CSA-C22.2, No. 60601-1, AAMI ES 60601-1, and IEC 80601-2-35.
Indicates high temperature part or component. The maximum temperature of this internal
component allowed by the protective system is also listed.
Indicates that only sterile or distilled water should be used when filling the A
Management System Control Module.
Identifies Patient Temperature 1, the patient temperature probe input for monitoring
and control.
Identifies Patient Temperature 2, the patient temperature probe input for monitoring
Identifies the drain port.
Indicates electrical hazard.
Identifies the storage temperature range.
Identifies the storage relative humidity range.
Manufacturer
Do not re-use.
Risk of overbalance due to pushing, leaning, resting, etc.
A S 5000 Temperature Management System must be disposed of properly.
®
rctic un
DO NOT dispose of into the garbage.
O P E R A T O R ' S M A N U A L
S Temperature
®
rctic un
