1.

INTRODUCTION

Dear Customer,
Thank you for choosing a machine from the Ritmo range of products.
This handbook and its enclosure have been prepared by the manufacturer for the purpose
of illustrating the features and usage of the Elektra welder. They contain all the information
and recommendations you need for the safe and proper use of the equipment by trained
welders. We urge you to read completely both the handbook and its enclosure before
using the welding equipment. We also advise you to keep these papers with the machine
for future reference and/or eventual next users.
We are sure that you will soon become familiar with your new equipment and that it will
give you many years of entirely satisfactory service.
2.

MACHINE'S DESCRIPTION

Elektra Light is a multipurpose low voltage (8÷48V) electrofusion machine capable of fusing
any brand of HDPE, PP, PP-R couplers available in the market for the transport of gas, water,
and other fluids under pressure, up to OD 125mm.
The Elektra Light can be used in two different manners:
-With the barcode reader, in which case the machine automatically sets the
welding parameters by reading off the information contained on the bar code,
according to the ISO13950 Standard, whether the operator reads the bar code
with the barcode reader or inserts the characters underneath it, manually.
-Without the barcode reader, in which case the operator must set in the voltage
and the welding time, as per the instructions given by the manufacturer of the
coupler.
The Elektra Light has a memory capacity of up to 325 welding cycles, downloadable to a
USB flash drive or a serial printer (via adapter DB9M-USB on request).
3.

TECHNICAL FEATURES

Diameters range (OD)
Weldable materials
Dimensions (W x D x H)
Weight
Power supply
Frequency
Nominal power
Nominal current
5
Nominal welding
current
(ISO 12176-2)
Working Temperature
Welding voltage
Peak Current
4
OD 160mm couplers can also be welded but with precaution; wait for the machine to cool off completely
after each welding cycle.
5
Power at 60% duty cycle
Duty cycle 100%
Duty cycle 60%
Duty cycle 30%
ELEKTRA LIGHT
110V
20 ÷ 125
HDPE / PP / PP- R
200 x 250 x 210 mm
8 kg
110 V  10%
50 ÷ 60 Hz
1300W
11.8A
15A
23A
29A
–10 °C ÷ + 50 °C
8 ÷ 48 V
60 A
Kindest regards,
Ritmo S.p.A.
230V
4
230 V  15%
5.7A
