EN
Element
Reset
Disconnection
Cooling air demand
Heating air demand
Speed 1
Speed 2
Speed 3
Cooling air demand
Heating air demand
8
F 0
Abbreviation
COOL
HEAT
Fan
SW5
SW2
Y 0
W 0
Allows you to reset the device to factory
SW2
SW5 Push button for mains disconnection
Relay output (12 V)
Relay for control of cooling on/off valve
Relay for control of heating on/off valve
FL Relay for control of low fan speed
FM Relay for control of medium fan speed
FH Relay for control of high fan speed
0-10 V outputs
Output for control of proportional cooling
Y 0
Output for control of proportional heating
W 0
F 0 Output for proportional control of fan speed
COOL
HEAT
FL
FM
FH
Description
settings
valves
valves
