ENGLISH

BATTERY COMPARTMENT CLEANING

Clean any liquid from the bottom of the battery compartment (A,
Fig. 8).
1. Drive the machine to the appointed disposal area.
2. Open the valve (B) under the solution tank and drain the
liquid from the bottom of the battery compartment.

DETERGENT TANK CLEANING

Clean the detergent tank (42) according to the following
procedure:
1. Drive the machine to the appointed disposal area.
2. Open the cover (20) and check that the recovery tank (19)
is empty, otherwise empty it with the drain hose (24). Close
the cover (20).
3. Carefully lift the tank assembly (44).
4. Unscrew the plug and disconnect the hose (A, Fig. 9) from
the tank (B).
5. Remove the tank.
6. Wash the tank in the appointed disposal area.
7. Install the tank (42) in the position shown in the figure and
connect it to the hose (A).
8. When the detergent tank has been drained, the EcoFlex™
system must be drained too (see the procedure in the
following paragraph).
ECOFLEX™ SYSTEM DRAINING
1. Clean the detergent tank according to the procedure shown in the previous paragraph. To remove the detergent remained in
the hoses and in the pump, perform the following procedure.
2. Turn on the machine by turning the ignition key (58) to "I" position.
3. Press the switch (53). Check that the switch LED (54) turns on.
4. Press the switches (53 and 59) at the same time, until the switch LED (54) starts flashing (after about 5 seconds).
5. Release the switches and wait for the LED (54) to stop flashing and for the vacuum system to turn on.
6. Collect the detergent remained on the floor.
7. Turn the ignition key (58) to "0".
8. Lift the tank (19), then check that the detergent tank hose (42) is empty, otherwise perform steps 3 to 7 again.
NOTE
The draining cycle lasts about 30 seconds, then the vacuum function automatically turns on, which allows to remove the
detergent remained.
The draining cycle can also be performed with the detergent tank (42) full of water, thus cleaning the system thoroughly.
It is advisable to perform this type of draining to clean the EcoFlex™ system from dirt and deposits if the machine has
not been used/cleaned for a long time.
The draining cycle can be performed also to quickly fill the detergent supply hose when the tank (42) is full but the
system is still empty.
If necessary, the draining cycle can be repeatedly performed.
26
INSTRUCTIONS FOR USE
SC3000 26 D - 9098827000
