10. Additional Functions

Adjusting Fade In Time for the Color Channels
It is possible to adjust a fade in time for chases affecting
the RGBW color channels 1-4 and the dimmer channel.
When actuating a sliding control, the corresponding chan-
nel is moved slowly and steadily to its target value. The
controller automatically creates all necessary intermedi-
ate values. Keep the PAGE button pressed and simultane-
ously adjust the fade in time with the PAN wheel between
0-30 seconds. When turning the wheel, the display indi-
cates the selected value in the lower line, e.g. "Fade 8.5S"
for a fade in lasting 8.5 seconds. The fade in feature can be
assigned to each fixture individually. The assignment can
be made in the system settings under "01. Patch fixture"
(!section 6.7).
Blackout Function
With the blackout function it is possible to blackout a
scene or chase completely. Current fadings and chases are
not stopped by the blackout function, they continue "in
the dark" in the meantime.
1. With the BLACKOUT button this function is switched
on: The LED above the button flashes and all control chan-
nels are set to the output value zero.
2. By pressing the BLACKOUT button again, the function
stops: The LED is extinguished and all channels return to
their pervious output values.
3. In the system settings, it is possible to define whether
all control channels react to the BLACKOUT button or only
the dimmer control channel.
