Number Element
1 Motorized Fad-
ers
2 Fixture Buttons
3 Page Buttons
4 Pan/Tilt Button
5 Page UP/Clear
Button
P. 10
NAVIGATOR EXPERT RDM
ENGLISH VERSION
Function
• For adjusting the DMX values of the connected light
effect units. The current DMX value is indicated in the display.
The faders are split into 4 pages so that 4 x 8 DMX channels
and both movement channels can be controlled.
(i.e. up to 34 DMX channels per fixture).
To select and deselect up to 24 devices on three pages. The
buttons light to indicate which devices are selected.
To switch the FIXTURE buttons between the 3 fixture pages.
LED A lights: page A is selected (fixtures 1-8).
•
• LED B lights: page B is selected (fixtures 9-16).
LED C lights: page C is selected (fixtures 17-24).
•
LED off: The PAN/TILT wheels control the channel.
•
LED on: The PAN/TILT wheels control the special
•
features such as movements.
To switch the faders (1) between the four pages. Each
•
time the button is pressed, the controller will advance one
page. The LEDs above the button indicate which page is se-
lected at that moment.
Keep this button pressed for 3 seconds to set all ad-
•
justments made through the faders and encoder wheels to 0.
