Translation of the original instructions
The manufacturer does not incur any responsability regarding damages to both objects and persons that result from an incorrect
and/or dangerous use of the machine.
Stray welding currents/voltages may destroy earth conductors, damage electrical equipment or cause components to warm up
which may cause a fire.
- All welding connections must be firmly secured, check regularly !
- Check that the metal piece fixation is strong and without any electrical problems !
- Attach or hang all the electrically conductive elements,such as the trolley in order to insulate them.
- Do not place any electrical equipment such as drills on top of the welding machine without insulating them !
- Always place welding torches or electrodes holders on an insulated surface when they're not in use !
MAINTENANCE / RECOMMENDATIONS
• Maintenance should only be carried out by a qualified person. Annual maintenance is recommended.
• Ensure the machine is unplugged from the mains, and wait for two minutes before carrying out maintenance work.
DANGER High Voltage and Currents inside the machine.
• Remove the casing 2 or 3 times a year to remove any excess dust. Take this opportunity to have the electrical connections
checked by a qualified person, with an insulated tool.
• Regularly check the condition of the power supply cable. If the power cable is damaged, it must be replaced by the
manufacturer, its after sales service or an equally qualified person.
• Ensure the ventilation holes of the device are not blocked to allow adequate air circulation.
• Do not use this equipment to thaw pipes, to charge batteries, or to start any engine.
INSTALLATION – PRODUCT OPERATION
DESCRIPTION
This manual contains safety and operating instructions. Read it carefully before using the device for the first time and retain for future
reference. MULTIPEARL AUTO are multiprocess welding machines (MMA, TIG & MIG/MAG) with Synergy Technology for MIG/MAG.
They are suitable for welding steel, stainless steel and aluminium. Easy and quick to set up thanks to the Synergic mode
It is recommended to use the welding cables supplied with the unit in order to obtain the optimum product settings..
POWER SUPPLY
This machine is fitted with a 16A socket type CEE7/7 which must be connected to a single-phase 230V (50 - 60 Hz) power supply
fitted with three wires and one earthed neutral.
The absorbed effective current (I1eff) is displayed on the machine, for optimal use. Check that the power supply and its protection
(fuse and/or circuit breaker) are compatible with the current needed by the machine. In some countries, it may be necessary to
change the plug to allow the use at maximum settings.
Do not use an extension cord with a cross-section of less than 2.5 mm².
MACHINE DESCRIPTION (FIG I)
1 - Control panel
2 - Positive Dinze connector
3 - Negative Dinze connector
4 - Polarity reversal cable
5 - Euro torch connector
DESCRIPTION IHM ( FIG III)
1 Adjusting the welding position
2
Setting the welding mode
3 Adjusting the flare management
SWITCHING ON
The ON/OFF switch is located at the back of the machine. Turn the switch on the "I" position to start the generator. This switch
must not be turned off (to "O") while welding.
20
MULTIPEARL AUTO
6 - Reel adaptor 200/300mm
7 - Power lead (2.10 m)
8 - Quick release gas connector.
9 - ON/OFF switch
4 Upper knob
5
Lower knob
