Airfusion Flusso Installation Instructions
INSTALLING THE MOUNTING BRACKET
Pass the power supply wires (C) from the ceiling outlet box (B) through the center of the ceiling mounting
bracket (D). Install the ceiling mounting bracket (D) on the outlet box (B) with the mounting screws (F) provided
with the outlet box and washers (E) provided with fan. Fig. 5
HANGING THE FAN MOTOR ASSEMBLY
Lift the fan assembly (1) up to the mounting bracket. Hang the fan assembly onto the J-hook (2) of the
⚫
mounting bracket. (Fig.6)
Complete the electrical wiring according to the 'ELECTRICAL WIRING DIAGRAM' section below. (Fig.7)
⚫
Noted: The Flusso fan is a DC technology fan and cannot be used with an AC wall switch. If use wall
switch, on/off toggle wall switch – only, Always leave in the "on" position and use remote.
4 | P a g e

HANGING THE FAN

2
Fig. 6
Fig. 5
1
V 1 . 0 ( 0 7 / 2 0 2 1 )
