Batteries And Sim Card (Optional Only Im100) - Messko MLog IM50 Instrucciones De Servicio

2 Commissioning
Number Description
1 x Assembly kit
4x hex . nut
4x washer
4x spring washer
1 x Information label „Transport is
under surveillance"
2.2 Batteries and SIM card (only optional for IM100)
To replace the MLog batteries, unscrew the 10 Phillips-head screws on the rear of the MLog and remove the back .
The unit requires 6x LR14 alkaline batteries .
If you have an MLog IM100 with optional GSM module, you can now insert a SIM card into the SIM card holder .
NOTE
The SIM card must be inserted only with deactivated GSM
module and after prior entry of the PIN .
6x LR14
alkaline
batteries
(Varta 4014)
NOTE
Use only standard alkaline batteries of the LR14
type .
Do not recharge alkaline batteries!
BA3431002/04 ES-EN
Figure
NOTE
Please dispose of used batteries
in a proper manner!
Remove the batteries if the device is not going to
be used for a prolonged period . There is a risk that
the batteries will leak as soon as they are depleted .
Observe the note on the following page!
SIM card holder
Backup battery
for internal clock
19
