GENERAL SPECIFICATIONS
STANDARD EQUIPMENT:
WEIGHT (dry fuel tank)
TIRES
TIRE PRESSURE
LOAD CAPACITY
REFRESHMENT UNIT
LOAD CAPACITY
GROUND CLEARANCE
CHASSIS
BODY & FINISH
SAFETY
LIGHTING PACKAGE
STEERING WHEEL
BRAKES
FRONT SUSPENSION
REAR SUSPENSION
STEERING
DASH PANEL
SEATING
ENGINE
VALVE TRAIN
LUBRICATION
BALANCER
IGNITION
CARBURETOR
AIR CLEANER
DRIVE TRAIN
ELECTRICAL SYSTEM
TRANSAXLE
FUEL TANK
SPEED
Specifications subject to change without notice
Page 28
REFRESHER
1,054 lbs (478 kg) fuel capacity 36 lbs (16 kg)
Front - 18 x 8.50 x 8 (4 ply rated), 18 x 9.50 x 8 (6 ply rated)
18 - 22 psi (124 - 152 kPa)
1200 lbs (544 kg) (including operator, passenger, cargo and accessories)
500 lbs (227 kg)
5 in (12.7 cm) at differential
Welded high yield strength tubular steel with powder coat paint
Front: Flexible, impact resistant panels. Color coat/clear coat finish
Rear: Lightweight, replaceable steel panels
Dash mounted key switch, reverse warning indicator, 'deadman' accelerator control, integral
handgrip on hip restraints, manual forward/reverse selector, electric horn, poly carbonate windshield
Dual halogen headlights, optional taillights, brake lights, turn signals
Dual handgrips
Dual rear wheel mechanical, self-adjusting drum brakes. Combination service / park brake with
automatic parking brake release (accelerator kick-off). Optional hydraulic front disc brakes
Heavy duty leaf springs with hydraulic shock absorbers
Heavy duty leaf springs with hydraulic shock absorbers
Self-compensating single reduction rack and pinion
Scuff resistant with four drink holders, fuel gauge, low oil pressure indicator light
Formed fabric backed vinyl covers over cushion foam. Seating for operator and one passenger
11 hp (8.2 kW) rated, 4 cycle, 350cc twin cylinder air cooled
Overhead valve, overhead cam, belt drive
Pressurized oil system, washable permanent filter
Internal counter-rotating balance shaft
Solid State, electronic timing advance and RPM limiter
Fixed jet, remote pulse fuel pump
Replaceable dry cartridge element
Automatic, continuously variable transmission (CVT)
External starter/generator, Solid State regulator, 12 volt maintenance free battery, 425 CCA, 60
minute reserve
High efficiency differential with helical gears, 13.32:1 ratio, ground speed governor, forward and
reverse with neutral lock
6 gal (23 L)
13 mph ± .5 mph (21 kph ± .8 kph)
