Liste Des Pieces - Techness RUN 200 Manual De Usuario

Code
Ref.
Usine
N01
N02 041800001
N03 052500002
N04 041100004
N05 020100004
N06 021000001
N07 022000002
N08
N09 052500001
N10 020900002
N11 022000003
N12 021000002
N13 020000005
N14
N15 020800002
N16 020100003
N17 020200004
N18 040200001
N19 040200002
N20 049900011
N21 053000012
N22 052000001
N23 040800008
N24 020200003
N25 040800004
N26 032800002
N27 037500003
N28 026200001
N29 013000039
N30 020100002
N31
N32 053000007
N33 020000013
N34 020300001
N35 020300002
N36 030000003

LISTE DES PIECES

Description
bottom steel bracket
Φ60 moving wheel
adjustable cushion
upright lower cover
cup head hex screw
flat washer- Class C
1 non-metal hex nut
incline steel bracket
rubber cushion
hex bolt
1 non-metal hex nut
flat washer- class C
hex bolt
main steel bracket
cross screw
cup head hex screw
hex screw
left endcap
right endcap
cushion
running deck rubber plate
rubber cushion
30*20 endcap
hex screw
40*25 endcap
speed sensor
magnetic circle
gas spring
flat washer
cup head hex screw
motor support bracket
motor cushion plate
hex bolt
hex bolt
hex bolt
motor
44
Specification
Acier
Φ60*25
Φ44.2*35
705*180*55mm
M8*45 tooth: 20mm
Φ8
M8
Acier
35*Φ20
M10*28
M10
Φ10
M10*65 tooth:20mm
Acier
ST4.2*13
M8*40 tooth: 15mm
M8*80 full tooth
111.5*106*77.5mm
111.5*106*77.5mm
φ25*φ10.5*T2.0mm
45*33*T3.0
Φ30*20, with M8 nut
for 30*20*1.5 tube
M8*55 full tooth
for 40*25 tube
900mm 2PIN
DF-LG-102
10KG/644mm
￠16*￠8.5*T3.5
M8*35 full tooth
Acier
100*92.5*T1.5
M8*30
M8*12 full tooth
M8*35 tooth: 15
1.75HP, 180V
Qté.
1
4
4
1
8
33
14
1
2
4
4
10
1
1
13
3
2
1
1
2
4
2
2
1
2
1
1
1
2
1
1
1
2
4
2
1
