Connections and Setup

Make sure your device is connected properly as shown below.
1
3
Antenna In
Connects over-the-air
antenna
ANT IN
HDMI IN
HDMI OUT
DC 12V
USB From
TO TV
Streaming Device
4
HDMI IN from
Streaming
2
Device
HDMI to
TV
HDMI Output
®
Provides high-definition digital
audio and video to the TV
Note: Only use high-quality
HDMI and USB cables from
major manufacturers.
