SECTION 1
5. AWS C5.5 - "Recommended Practices for Gas Tung-
sten Arc Welding"
6. AWS C5.6 - "Recommended Practices for Gas Metal
Arc Welding""
7. AWS SP - "Safe Practices" - Reprint, Welding Hand-
book.
8. ANSI/AWS F4.1, "Recommended Safe Practices for
Welding and Cutting of Containers That Have Held
Hazardous Substances."
Enclosure Class
The IP code indicates the enclosure class, i.e. the degree of protection against penetration by solid objects or
water. Protection is provided against touch with a finger, penetration of solid objects greater than 12mm and
against spraying water up to 60 degrees from vertical. Equipment marked IP23S may be stored, but is not
intended to be used outside during precipitation unless sheltered.
CAUTION
If equipment is placed on a surface that
slopes more than 15°, toppling over may oc-
cur. Personal injury and / or significant dam-
age to equipment is possible.
To avoid personal injury and/or equipment
damage, lift using method and attachment
points shown here.
This product is solely intended for plasma cutting. Any other
use may result in personal injury and / or equipment damage.
CAUTION
CAUTION
SAFETY PRECAUTIONS
MEANING OF SYMBOLS - As used
throughout this manual: Means Atten-
tion! Be Alert! Your safety is involved.
Means immediate hazards which,
if not avoided, will result in im-
mediate, serious personal injury
or loss of life.
Means potential hazards which
could result in personal injury or
loss of life.
Means hazards which could result
in minor personal injury.
MaximumTilt
Allowed
15°
