SECTION 3
2. Insert the free end of the Extension Cable through the grommet on the end of the RJB and make the
power and gas connections as shown.
3. Insert the free end of the PT-37 Torch through the grommet on the other end of the RJB and make the
power and gas connections as shown.
To PT-37 Torch
Power Connection
Figure 3-9. Remote Junction Box Connections
4. Replace all covers and hardware.
Torch Cable
Air Connection
Torch Cable
Extension Cable connections from
the ESP-101 must be connected
on the solenoid wiring side of the
(Torch connection side is labeled.)
Extension Cable
Air Connection
22
INSTALLATION
Note:
Remote junction Box.
Extension Cable
Power Connection
Extension Cable
From ESP-101
