Pushbutton lighting mode selection
5.

5.1 Lighting modes

- Users may choose between 3 different lighting modes for the product selection buttons.
a. MODE 1 LIGHTING
By default all buttons remain off, when a
button is pressed, it lights up and the others
remain off.
b. MODE 2 LIGHTING
By default all buttons are lit up, when a button
is pressed, it turns off and the others remain
lit up.
c. MODE 3 LIGHTING
By default all buttons are lit up, when a button
is pressed, this one remains lit up and the
others turn off.

5.2 Procedure for changing the lighting mode

1. Switch the machine off at the general switch.
Start the machine by turning the general switch on and wait for the "VISACREM V6 +" or "GAGGIA G6 +" light located on the right
2.
of the front panel to turn off (refer to figure 1).
3. Hold the small coffee and continuous coffee buttons on the left group pressed at the same time until the buttons for one small
coffee, two small coffees and one large coffee start flashing (refer to figure 2), indicating the machine has entered into "Indication
mode".

Press the "one short coffee" button to select "Mode 1".

Press the "two short coffees" button to select "Mode 2".

Press the "one large coffee" button to select "Mode 3".
Once the preferred mode has been selected, wait until the machine consecutively tests all the groups by turning each one of the groups
on and off. Once the auto test has concluded, the machine will be ready to operate.
Turn the machine on by means of the
general switch.
Once the light of the "Gaggia" or "Visacrem" brand turns off, press and hold down the buttons for
one small coffee and continuous at the same time on the left group
Left button panel
The buttons for one small, two small and one large coffee will start flashing.
Mode 1.
Mode 3.
Mode 2.
33
45%
Figure 1.
Figure 2.
