General Description Of Ruby; General Overview; Product Selection Buttons - Quality Espresso Ruby Office Manual De Usuario

2.

General Description of Ruby

2.1 General Overview

12
11
10
9
1- Hot Water Tap

2- Product Selection Buttons

3- Steam Tap
4 - Water Tank
2.2 Product Selection Buttons
Electronic
b
version
a
d e
a - One Coffee
b - Continuous Coffee
c - Two Coffees
2
1 3
4
8
7
I Level indicator
5 - Power Switch
6 - Steam Arm
7 - Feet
8 - Drip Tray
c
f
f
15
Water Supply
Element Wattage
Boiler Capacity
Tank Capacity
Water pump
5
A = 367 mm
B = 306 mm
C = 511 mm
A
6
B
9 - Drain Tray
10 - Boiler Pressure Gauge
11 - Filter Holder
12 - Hot Water Outlet
b
d e
d - Boiler Water Level Indicator
Boiler
e - Tank Water Level Indicator
f - Heating Element Indicator
Internal Tank
1.500 W (230 V)
1.5 L
3 L
Vibr. Pump 18 bar
C
Semiautomatic
version
f
GB
