About the temperature controls – GE, Monogram Models.
The unit will have one of the temperature controls shown below:
Internal Temperature
Controls
External Controls
GE Models
Set Point
Control
Actual Temp
Control
The temperature controls are preset in the factory at 5 for both the refrigerator and freezer compartments for the
Set Point Controls or to 3/-18ºC for Actual Temp Controls.
To adjust the Set Point temperature, press the WARMER or COLDER button on either the Freezer or Refrigerator side.
The set point light will come on. Press WARMER or COLDER until the desired setting is reached.
To adjust the Actual Temp temperature, first press the Freezer
buttons (or the or ) to increase or decrease temperature to the desired setting. Repeat for the other compartment.
Several adjustments may be required. Each time you adjust controls, allow 24 hours after each adjustment for the
refrigerator to reach the setting you have selected.
Setting either or both controls to 0 stops cooling in both the freezer and refrigerator compartments, but does not shut
off electrical power to the refrigerator.
Control settings will vary based on personal preferences, usage and operating conditions and may require
more than one adjustment.
NOTE: The refrigerator is shipped with protective film covering the temperature controls. If this film was not removed
during installation, remove it now.
Ambient temperature limits
This refrigerator is designed to operate in ambient temperatures specified by its Temperature Class, which is marked on
the rating plate.
Temperature Symbol
Class
Extended-
Temperate SN
Temperate N
Subtropical ST
Tropical T
NOTE: Internal temperature may be affected by such factors as the location of the refrigerator, ambient temperature
and frequency of door openings. Adjust temperature controls as required to compensate for these factors.
Ambient Temperature
Maximum Minimum
32°C 10°C
32°C 16°C
38°C 16°C
43°C 16°C
or Refrigerator button. Then press the or
