DC Voltage Measurement:
Select measurement range V
switch.
Connect the black test lead to the COM socket and the red test lead to
the socket.
Connect test leads to UUT.
Read the measurement result displayed on the screen.
AC Voltage Measurement:
Select measurement range V
switch.
Connect the black test lead to the COM socket and the red test lead to
the socket.
Connect test leads to UUT.
Read the measurement result displayed on the screen.
-
DC Voltage Measurement
via measurement function selection
via measurement function selection
+
-
AC Voltage Measurement
+
