MENU GUIDE
II. INSTALLATION
f) Motor Control
Select the position using
Message box displays on the screen.
- Store Sat position : Stores the current position
- Goto Sat Position : Moves the motor to the stored
- Goto Center : Goes to the center of the motor.
- Limit off : disable East, West limit.
- Set East Limit : Set current position as East Limit.
g) Satellite Position
- Input directly the position using NUMBER KEY on
the RCU
- Select the direction using
h) Search Option
- Press OK to display the Search Option list.
- Select the Search Option that you want and then
press OK.
2. Edit my local position
- Press Green Button to edit local Position.
a) Longitude
- Input directly the Longitude using NUMBER KEY on the RCU.
- Select the direction using
b) Latitude
- Input directly the Latitude using UNMBER KEY on the RCU.
- Select the direction using
3. Press EXIT to return to the previous menu or press MENU to go to the current live channel.
MAX_COMBO_NET_manual_print REV2.0.pdf 21 MAX_COMBO_NET_manual_print REV2.0.pdf 21
and then press OK.
of the motor for the selected
satellite.
position of the selected satellite.
(WEST / EAST).
(WEST / EAST).
(NORTH/SOUTHd).
- Set West Limit : Set current position as
West Limit.
- Recaluation Position.
- Reset Position : Resets all stored position
of the motor.
i) Search
- Press Search to start scan channels.
- Press OK to start scanning.
TP EDIT : To Edit TP Press the RED button on
the RCU.
17
