ANBAUANLEITUNG
mounting instructions • instructions de montage • instrucciones de montaje • istruzioni di montaggio
HDG.00.220.21100/B
beinhaltet • contains • contient • contiene • contiene
HDG.00.220.81100/B
HDG.00.220.10300/B

Publicidad

Tabla de contenido
loading

Resumen de contenidos para SW-Motech HDG.00.220.21100/B

  • Página 1 ANBAUANLEITUNG mounting instructions • instructions de montage • instrucciones de montaje • istruzioni di montaggio HDG.00.220.21100/B beinhaltet • contains • contient • contiene • contiene HDG.00.220.81100/B HDG.00.220.10300/B...
  • Página 2 Angaben des Fahrzeugherstellers wieder eingebaut oder durch Irrtümer vorbehalten. Technische und gestalterische Änderungen sind von SW-MOTECH gelieferte Teile und Hardware ersetzt werden. vorbehalten. Das Urheberrecht liegt bei SW-MOTECH.  WARNUNG: Sichern Sie alle Gewinde, sofern nicht anders angegeben, mit mittelstarker, flüssiger Schraubensicherung.
  • Página 3 Schraubensicherung verwenden: Weist darauf hin, Anziehen / Anzugsmomentangabe beachten: Weist auf dass ein Gewinde mit flüssiger Schraubensicherung das von SW-MOTECH bzw. vom Fahrzeughersteller (OEM) bestrichen werden muss. H (HIGH): hohe Festigkeit; vorgegeben Anzugsmoment eines Teils hin. M (MEDIUM): mittlere Festigkeit; L (LOW): niedrige Festigkeit.
  • Página 4 STüCKLISTE · ANBAUANLEITUNG LESEN UND AUFBEWAHREN! M8 x 35; DIN 6912 HDG.00.220.032L.25 HDG.00.220.032R.25 SC.ST.08.035.02.6912.088 HDG.00.220.011.25 HDG.00.220.073.35 LVG.06.861.001.35 Die inhaltliche Übersetzung erfolgt automatisiert. Irrtümer und Änderungen vorbehalten. © SW-MOTECH GmbH & Co. KG Technische und Design-Änderungen vorbehalten.
  • Página 5 Kontrolleinheiten nicht korrekt funktionieren oder zu bedienen sind! Führen Sie VOR jeder Fahrt eine vollständige Funktionskontrolle des Lenkers und aller Armaturen durch! Die inhaltliche Übersetzung erfolgt automatisiert. Irrtümer und Änderungen vorbehalten. © SW-MOTECH GmbH & Co. KG Technische und Design-Änderungen vorbehalten.
  • Página 6  HINWEIS: Beachten Sie die landesspezifischen Vorschriften für Zulassung/Betrieb Ihres Fahrzeugs bzw. anwendbare TÜV-Vorschriften. Lassen Sie eintragungspflichtige Teile nach Montage durch Ihre Prüfstelle in die Fahrzeugpapiere eintragen. Die inhaltliche Übersetzung erfolgt automatisiert. Irrtümer und Änderungen vorbehalten. © SW-MOTECH GmbH & Co. KG Technische und Design-Änderungen vorbehalten.
  • Página 7: Functional Check

    ~ 0.5 h. EASY DIFFICULT ENGLISH ·Thank you for choosing this premium product from SW-MOTECH. PREPARATION: Read the mounting instructions carefully and make sure Visit our online shop for more information (e.g. model assignments). Required that all parts on the parts list are available.
  • Página 8 Indicates the tightening torque of a part specified by SW- strength; M (MEDIUM): medium strength; L (LOW): MOTECH or the vehicle manufacturer (OEM). low strength. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Página 9 PARTS LIST · READ AND KEEP MOUNTING INSTRUCTIONS! M8 x 35; DIN 6912 HDG.00.220.032L.25 HDG.00.220.032R.25 SC.ST.08.035.02.6912.088 HDG.00.220.011.25 HDG.00.220.073.35 LVG.06.861.001.35 The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Página 10 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS!  WARNING: The installation of this handguard mounting kit may × compromise the safety of your vehicle; SW-MOTECH recommends having the assembly/maintenance of the product carried out by a specialized professiona!  WARNING: Always wear eye and hand protection! ...
  • Página 11 TÜV regulations. After assembly, have parts that are subject to registration entered in the vehicle documents by your test centre. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Página 12: Preparación

    Nos reservamos el derecho a realizar cambios o sustituidas por piezas y herrajes suministrados por SW-MOTECH. técnicos y de diseño. Los derechos de autor pertenecen a SW-MOTECH.  ATENCIÓN: Asegure todas las roscas con fijador de roscas líquido de resistencia media, a menos que se especifique lo contrario.
  • Página 13 Usar fijador de roscas: Indica que una rosca debe Respete la información del par de apriete: Indica el par recubrirse con fijador de roscas líquido. H (HIGH): de apriete de una pieza especificada por SW-MOTECH o el resistencia alta; M (MEDIUM): resistencia media; L fabricante del vehículo (OEM).
  • Página 14 LISTA DE PIEZAS · LEE Y CONSERVA LAS INSTRUCCIONES DE MONTAJE! M8 x 35; DIN 6912 HDG.00.220.032L.25 HDG.00.220.032R.25 SC.ST.08.035.02.6912.088 HDG.00.220.011.25 HDG.00.220.073.35 LVG.06.861.001.35 La traducción del contenido es automática Salvo errores y omisiones © SW-MOTECH GmbH & Co. KG Sujeto a cambios técnicos y de diseño.
  • Página 15 ANTES de cada salida, ¡compruebe bien que el manillar y todos los accesorios funcionan correctamente! La traducción del contenido es automática Salvo errores y omisiones © SW-MOTECH GmbH & Co. KG Sujeto a cambios técnicos y de diseño.
  • Página 16 La traducción del contenido es automática Salvo errores y omisiones © SW-MOTECH GmbH & Co. KG Sujeto a cambios técnicos y de diseño.
  • Página 17: Contrôle Du Fonctionnement

     ATTENTION Sauf indication contraire, sécurisez tous les filetages avec les droits d'auteur. du frein filet liquide de force moyenne.  DANGER : Les couples de serrage non définis par SW-MOTECH doivent SYMBOLE D'AVERTISSEMENT DE SÉCURITÉ être obtenus auprès du constructeur du véhicule ou d'un atelier de ...
  • Página 18 H (HIGH) : haute serrage : indique le couple de serrage d'une pièce résistance ; M (MEDIUM) : force moyenne ; L (LOW) : prescrit par SW-MOTECH ou par le fabricant du véhicule faible résistance. (OEM).
  • Página 19 LISTE DES PIèCES · LIRE ET CONSERVER LES INSTRUCTIONS DE MONTAGE! M8 x 35; DIN 6912 HDG.00.220.032L.25 HDG.00.220.032R.25 SC.ST.08.035.02.6912.088 HDG.00.220.011.25 HDG.00.220.073.35 LVG.06.861.001.35 La traduction du contenu est automatisée. Sous réserve d'erreurs et de modifications © SW-MOTECH GmbH & Co. KG Sous réserve de modifications techniques et de design.
  • Página 20 AVANT chaque utilisation, effectuez un contrôle complet du fonctionnement du guidon et de toutes les commandes ! La traduction du contenu est automatisée. Sous réserve d'erreurs et de modifications © SW-MOTECH GmbH & Co. KG Sous réserve de modifications techniques et de design.
  • Página 21 Après le montage, faites inscrire les pièces soumises à immatriculation dans les papiers du véhicule par votre centre de contrôle. La traduction du contenu est automatisée. Sous réserve d'erreurs et de modifications © SW-MOTECH GmbH & Co. KG Sous réserve de modifications techniques et de design.
  • Página 22 SIMBOLO DI SICUREZZA  PERICOLO: le coppie di serraggio non definite da SW-MOTECH devono  Questo simbolo di avvertenza è usato nelle presenti istruzioni di essere richieste al costruttore del veicolo o a un'officina certificata.
  • Página 23 H (ALTA): serraggio: indica la coppia di serraggio di un componente alta resistenza; M (MEDIA): media resistenza; L specificata da SW-MOTECH o dal produttore del veicolo (BASSO): bassa resistenza. (OEM). La traduzione dei contenuti è automatizzata.
  • Página 24 ELENCO DELLE PARTI · LEGGI E CONSERVA LE ISTRUZIONI DI MONTAGGIO! M8 x 35; DIN 6912 HDG.00.220.032L.25 HDG.00.220.032R.25 SC.ST.08.035.02.6912.088 HDG.00.220.011.25 HDG.00.220.073.35 LVG.06.861.001.35 La traduzione dei contenuti è automatizzata. Salvo errori e omissioni. © SW-MOTECH GmbH & Co. KG Soggetto a modifiche tecniche e di design.
  • Página 25 FASE DI MONTAGGIO · LEGGI E CONSERVA LE ISTRUZIONI DI MONTAGGIO!  AVVERTENZA: poiché il kit di montaggio paramani viene installato in una × zona del veicolo rilevante per la sicurezza, SW-MOTECH raccomanda che il montaggio e la manutenzione del prodotto vengano effettuati da un'officina specializzata qualificata! ...
  • Página 26 La traduzione dei contenuti è automatizzata. Salvo errori e omissioni. © SW-MOTECH GmbH & Co. KG Soggetto a modifiche tecniche e di design.
  • Página 27 Angaben des Fahrzeugherstellers wieder eingebaut oder durch Irrtümer vorbehalten. Technische und gestalterische Änderungen sind von SW-MOTECH gelieferte Teile und Hardware ersetzt werden. vorbehalten. Das Urheberrecht liegt bei SW-MOTECH.  WARNUNG: Sichern Sie alle Gewinde, sofern nicht anders angegeben, mit mittelstarker, flüssiger Schraubensicherung.
  • Página 28 Handfest anziehen: Weist darauf hin, dass das Anbauteil darauf hin, dass an der Stelle keine flüssige vorsichtig mit der Hand angezogen werden muss. Schraubensicherung notwendig ist. Die inhaltliche Übersetzung erfolgt automatisiert. Irrtümer und Änderungen vorbehalten. © SW-MOTECH GmbH & Co. KG Technische und Design-Änderungen vorbehalten.
  • Página 29 STüCKLISTE · ANBAUANLEITUNG LESEN UND AUFBEWAHREN! M3,5 x 12 HDG.00.220.004L.02 HDG.00.220.004R.02 HDG.00.220.006.02 SC.ST.035.012.02 Die inhaltliche Übersetzung erfolgt automatisiert. Irrtümer und Änderungen vorbehalten. © SW-MOTECH GmbH & Co. KG Technische und Design-Änderungen vorbehalten.
  • Página 30 Ziehen Sie die Schrauben (4) vorsichtig handfest (max 1,5 Nm) an. ×  WARNUNG: Zu festes Anziehen kann die Kunststoffteile beschädigen! × × Die inhaltliche Übersetzung erfolgt automatisiert. Irrtümer und Änderungen vorbehalten. © SW-MOTECH GmbH & Co. KG Technische und Design-Änderungen vorbehalten.
  • Página 31  HINWEIS: Beachten Sie die landesspezifischen Vorschriften für Zulassung/Betrieb Ihres Fahrzeugs bzw. anwendbare TÜV-Vorschriften. Lassen Sie eintragungspflichtige Teile nach Montage durch Ihre Prüfstelle in die Fahrzeugpapiere eintragen. Die inhaltliche Übersetzung erfolgt automatisiert. Irrtümer und Änderungen vorbehalten. © SW-MOTECH GmbH & Co. KG Technische und Design-Änderungen vorbehalten.
  • Página 32 ~ 0.25 h. EASY DIFFICULT ENGLISH ·Thank you for choosing this premium product from SW-MOTECH. PREPARATION: Read the mounting instructions carefully and make sure Visit our online shop for more information (e.g. model assignments). Required that all parts on the parts list are available.
  • Página 33 Tighten by hand: Indicates that the attachment must be thread lock should be used at this point. carefully tightened by hand. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Página 34 PARTS LIST · READ AND KEEP MOUNTING INSTRUCTIONS! M3,5 x 12 HDG.00.220.004L.02 HDG.00.220.004R.02 HDG.00.220.006.02 SC.ST.035.012.02 The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Página 35 Carefully tighten the screws (4) hand-tight (max. 1.5 Nm). ×  WARNING: Tightening too tightly can damage the plastic parts! × × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Página 36 TÜV regulations. After assembly, have parts that are subject to registration entered in the vehicle documents by your test centre. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Página 37 Nos reservamos el derecho a realizar cambios o sustituidas por piezas y herrajes suministrados por SW-MOTECH. técnicos y de diseño. Los derechos de autor pertenecen a SW-MOTECH.  ATENCIÓN: Asegure todas las roscas con fijador de roscas líquido de resistencia media, a menos que se especifique lo contrario.
  • Página 38 Apretar a mano: Indica que el componente se debe usar fijador de roscas líquido en este punto. apretar cuidadosamente a mano. La traducción del contenido es automática Salvo errores y omisiones © SW-MOTECH GmbH & Co. KG Sujeto a cambios técnicos y de diseño.
  • Página 39 LISTA DE PIEZAS · LEE Y CONSERVA LAS INSTRUCCIONES DE MONTAJE! M3,5 x 12 HDG.00.220.004L.02 HDG.00.220.004R.02 HDG.00.220.006.02 SC.ST.035.012.02 La traducción del contenido es automática Salvo errores y omisiones © SW-MOTECH GmbH & Co. KG Sujeto a cambios técnicos y de diseño.
  • Página 40 Apriete a mano y con precaución los tornillos (4) (máx. 1,5 Nm). ×  ATENCIÓN: ¡Apretarlos demasiado puede dañar las piezas de plástico! × × La traducción del contenido es automática Salvo errores y omisiones © SW-MOTECH GmbH & Co. KG Sujeto a cambios técnicos y de diseño.
  • Página 41 La traducción del contenido es automática Salvo errores y omisiones © SW-MOTECH GmbH & Co. KG Sujeto a cambios técnicos y de diseño.
  • Página 42  ATTENTION Sauf indication contraire, sécurisez tous les filetages avec les droits d'auteur. du frein filet liquide de force moyenne.  DANGER : Les couples de serrage non définis par SW-MOTECH doivent SYMBOLE D'AVERTISSEMENT DE SÉCURITÉ être obtenus auprès du constructeur du véhicule ou d'un atelier de ...
  • Página 43 à ce doit être serrée à la main avec précaution. stade. La traduction du contenu est automatisée. Sous réserve d'erreurs et de modifications © SW-MOTECH GmbH & Co. KG Sous réserve de modifications techniques et de design.
  • Página 44 LISTE DES PIèCES · LIRE ET CONSERVER LES INSTRUCTIONS DE MONTAGE! M3,5 x 12 HDG.00.220.004L.02 HDG.00.220.004R.02 HDG.00.220.006.02 SC.ST.035.012.02 La traduction du contenu est automatisée. Sous réserve d'erreurs et de modifications © SW-MOTECH GmbH & Co. KG Sous réserve de modifications techniques et de design.
  • Página 45  ATTENTION : Un serrage trop fort peut endommager les pièces en plastique ! × × La traduction du contenu est automatisée. Sous réserve d'erreurs et de modifications © SW-MOTECH GmbH & Co. KG Sous réserve de modifications techniques et de design.
  • Página 46 Après le montage, faites inscrire les pièces soumises à immatriculation dans les papiers du véhicule par votre centre de contrôle. La traduction du contenu est automatisée. Sous réserve d'erreurs et de modifications © SW-MOTECH GmbH & Co. KG Sous réserve de modifications techniques et de design.
  • Página 47 SIMBOLO DI SICUREZZA  PERICOLO: le coppie di serraggio non definite da SW-MOTECH devono  Questo simbolo di avvertenza è usato nelle presenti istruzioni di essere richieste al costruttore del veicolo o a un'officina certificata.
  • Página 48 Serrare a mano: indica che l'elemento di fissaggio deve utilizzare il frenafiletti liquido in quel determinato essere serrato a mano con cautela. punto. La traduzione dei contenuti è automatizzata. Salvo errori e omissioni. © SW-MOTECH GmbH & Co. KG Soggetto a modifiche tecniche e di design.
  • Página 49 ELENCO DELLE PARTI · LEGGI E CONSERVA LE ISTRUZIONI DI MONTAGGIO! M3,5 x 12 HDG.00.220.004L.02 HDG.00.220.004R.02 HDG.00.220.006.02 SC.ST.035.012.02 La traduzione dei contenuti è automatizzata. Salvo errori e omissioni. © SW-MOTECH GmbH & Co. KG Soggetto a modifiche tecniche e di design.
  • Página 50 Stringere con cautela le viti (4) a mano (max. 1,5 Nm). ×  AVVERTENZA: un serraggio eccessivo può danneggiare le parti in plastica! × × La traduzione dei contenuti è automatizzata. Salvo errori e omissioni. © SW-MOTECH GmbH & Co. KG Soggetto a modifiche tecniche e di design.
  • Página 51 La traduzione dei contenuti è automatizzata. Salvo errori e omissioni. © SW-MOTECH GmbH & Co. KG Soggetto a modifiche tecniche e di design.
