SW-Motech ADVENTURE RACK Instrucciones De Montaje página 10

1
1
GPT.02.059.001.11
1
/1
2
4
GPT.00.152.002.11
1
/1
The content translation is automated.
© SW-MOTECH GmbH & Co. KG
PARTS LIST · READ AND KEEP MOUNTING INSTRUCTIONS!
2 3
M6 x 20; DIN 7991 Ø 20 / ø 6,4 / h 8
SC.ST.06.020.48.7991.109 DB.ST.0200.0064.0080.02
4
/4
5 6
M6 x 16; ISO 7380 ø 6.4; DIN 9021
SC.ST.06.016.02.7380.109 US.ST.064.02.9021
4
/4
4
/4
4
/4
3
Errors and omissions excepted
Subject to technical and design changes.
