Parts List
Front with seal fitted
178113
620526
108111
x1
x1
x4
Back
60535
190SPR-1
x1
x1
190SPH-5
60536
x1
x1
1
For ø25mm (1") tube:
ø20mm (25/32") hole saw
For ø32mm (1 1/4") tube:
ø25mm (1") hole saw
04-06-21 Issue C
Tools Required
x2
60416
x1
60414
x1
60087
x2
x4
190SPR-1
4 x 620526
3
Hole Saw ø20 or
25mm (25/23" or 1")
Power drill
Drill Bit to suit
instrument fixings
Posidriv No. 3
Screwdriver
2.5mm Allen
Key
2
5
178111
1 x 190SPH-5
7
R MIN 82mm
(3.23")
1 x 178113
4
Fully Tighten to lock 60535
& 60536 together
60535
60414
2 x
60416
2 x
60087
4 x
