SUPPORTED CONFIGURATIONS

Sensor Type
Fuel Level
Freshwater Level
Wastewater Level
Trim Position
Rudder Angle
Coolant
Temperature
Boost Pressure
Oil Pressure
Oil Temperature
Gear Oil Pressure
Gear Oil
Temperature
Trim Tabs
* The supported configurations may be updated at any time. Please make sure to always use the latest App
version.
** There is always the option to add custom sensor curves as well.
Calibrations**
0 – 90 Ω
3 – 180 Ω
240 – 33 Ω
90 – 4 Ω
3 – 180 Ω
240 – 33 Ω
90 – 4 Ω
3 – 180 Ω
240 – 33 Ω
90 – 4 Ω
167 – 10 Ω (Single station)
84 – 5 Ω (Dual station)
10 – 180 Ω (Single station)
5 – 90 Ω (Dual station)
291 – 22 Ω (120 °C)
322 – 19 Ω (150 °C)
10 – 184 Ω (2 bar)
10 – 184 Ω (5 bar)
10 – 184 Ω (5 bar)
10 – 184 Ω (10 bar)
322 – 19 Ω (150 °C)
10 – 184 Ω (10 bar)
10 – 184 Ω (25 bar)
10 – 211 Ω (30 bar)
322 – 19 Ω (150 °C)
167 – 10 Ω (Single station)
84 – 5 Ω (Dual station)
Alarm available NMEA 2000® PGN
No
No
No
No
No
Yes
No
Yes
Yes
Yes
Yes
No
CONFIGURATION
127505
127505
127505
127488
127245
127489
127488
127489
127489
127493
127493
130576
B000647
