The noise level during operation can exceed 85 dB (A). Wear hearing protection!
Measured values determined in accordance with EN 62841-1.
Vibration total value .............................................................
The Vibration Total Value quoted in these instructions and the quoted noise emission values
were measured according to standardized measurement procedures and can be used to com-
pare one electric power tool with another. They can also be used to make an initial estimate of
the loading.
The quoted vibration and noise emissions can vary during actual use of the electric
power tool dependent on the way in which the electric power tool is used, in particular
what type of workpiece is being processed.
Establish additional safety measures to protect the operator which are based upon an
estimate of the vibration loading during the actual usage conditions (in doing so taking
account of parts of the operating cycle, for example times in which the electric power
tool is switched and those in which it is switched on but not running under load).
3 Technical Data charger and battery
Battery:
U = Voltage
C = Capacity
W = Weight
Ic = Charge current
t = Approx. charging time (90% full)
Charging voltage.............................
Charging temperature .. 0° - 50° C, 32° - 122° F
Max. discharging
temperature. ................................
Recharge battery pack before first use!
4

Scope of delivery

Variante 1:
RODRUM VarioClean basic
Guide tube
Operating manual
5

Function of the Unit

5.1 Overview
Drum
1
2 Control panel / Controller
3 Battery
4 Foot switch
5 Feed unit with clamping lever
5.2 Changing the battery
Slide the battery in up to the stop. Pull the battery out to remove it.
20
20,75 V DC
5° - 50° C, 41° - 122° F
Variante 2:
RODRUM VarioClean basic
Guide tube
Operating manual
Battery and charger in a case
ENGLISH
2
< 2,5 m/s ¦ K= 1,5 m/s
Charger:
U1 = Input voltage
f1 = Input frequency
P1 = Input power
U2 = Charging voltage
I2 = Max. charge current
Nc = No. of battery cells
W = Weight
Pay attention to the electrical outlet
voltage! Check the label on the
bottom of the charger!
Variante 3:
RODRUM VarioClean basic
Guide tube
Operating manual
Battery and charger in a case
Tool case
Drainage plug
6
7 Guide tube
8 Clamping grip
9 Lights
10 Tripod holder
2
(B1)
(E)
(A)
