Seat functions and operation

Lumbar support

With the upper and lower switch the curvature
in the upper and lower area of the backrest
upholstery can be individually adjusted.
This increases both the seating comfort and
the performance of the driver.
The lumbar support curvature can be
increased pressing "+" or reduced by pressing
"–" on the relevant switch.
When the backrest cushion does no longer
react to pressing "+", the maximum curvature
has been reached and the switch should be
released.

Armrests *

The armrests can be folded up if required and
the height individually adjusted.
To adjust the armrests for height, separate the
round cap (see arrow) from the cover (right
armrest +) or from the handle for backrest
adjustment (left armrest) and loosen the
hexagon nut (size 13 mm) behind it. Adjust
the armrests to the desired position (4 steps)
and tighten the nut again (25Nm). Replace
the cap onto the nut.

Armrest adjustment *

The inclination of the armrest can be modified
by turning the adjustment knob.
When turning the knob to the outside (+), the
front part of the armrest will be lifted; when
turning the knob to the inside (-), it will be
lowered.
