Dimensiones de gabiente: (BC300):

eFlow4N, eFlow4N8, eFlow4N8D
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm)
1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
(330mm)
5.10"
(130mm)
3.25"
(83mm)
1.0"
(25mm)
eFlow4N Series
1.40" 4.85"
(36mm) (123mm)
0.75"
(19mm)
13.0"
1.0"
(25mm)
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
1.40"
(36mm)
1.20"
(31mm)
3.25"
(83mm)
0.75"
(31mm)
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
3.25"
(83mm)
3.25"
(83mm)
1.0"
(25mm)
1.0"
(25mm)
1.20"
1.40"
(36mm)
5.10"
(130mm)
6.5625"
(167mm)
