ALFRA ROTABEST RB80X Manual De Instrucciones página 12

Technical Data
Prod. – No:
Name:
Input:
Load rpm:
Tool holder:
Voltage:
Boring Ø max. in steel
- Core cutter:
- Twist drills:
Stroke:
Size of magnet foot:
Magnetic adhesion:
Tool-Force:
(auf 10 mm Stahl)
Min. material thickness:
Weight:
Standard scope of supply
• Transport case (prod.-no. 189412037)
• MT-3 arbor (prod.-no. 18002)
• Coolant ALFRA BIO 4000 (prod.-no. 21040)
• Safety belt (prod.-no. 189490501)
• Allen key 2,5 mm DIN911-2,5
• Allen key 4,0 mm DIN911-4,0
• Allen key 6,0 mm DIN911-6,0
18780
Rotabest RB80X
1800 Watt
110 / 175 / 245 / 385 rpm
MT 3
230 V 50/60 Hz
12 - 80 mm ; 15/32" – 3"
up to Ø 30 mm DIN 338
190 mm + 100 mm adjustable height on slide
7,5" + 3,9" adjustable height on slide
92 x 220 mm ; 3,6" x 8,7"
13000 N ; 2900 lbs
4000 N ; 950 lbs
10 mm; 25/64"
19,5 kg ; 43 lbs
12
