FanEQ Control
► 1st FanEQ Group
► 2nd FanEQ Group
:Move Enter:Select +/-/PU/PD:Value
1st FanEQ Group
Click <Enter> key to enter its submenu (1st FanEQ Group):
CPU FanEQ Control
-Reference Temperature
-Control Temperature High
-Control Temperature Low
-Fan PWM Duty Cycle High
-Fan PWM Duty Cycle Low
SYS FanEQ Control
-Reference Temperature
-Control Temperature High
-Control Temperature Low
-DC Fan Voltage High
-DC Fan Voltage Low
AUX1 FanEQ Control
-Reference Temperature
-Control Temperature High
-Control Temperature Low
-DC Fan Voltage High
-DC Fan Voltage Low
:Move Enter:Select +/-/PU/PD:Value
CPU/SYS/AUX1 FanEQ Control
When set to [Enabled], these items control the CPU, SYS, and/or AUX1 fan speed by the
following setting combinations.
- Reference Temperature
This item selects the reference point for taking temperature among the available options of CPU,
SYS, and PWM Temperature, but there is only one "CPU Temperature" item to choose for the
"CPU FanEQ Control".
IN9 32X/IN9 32X-MAX
μGuru Utility v1.00C
ABIT EQ
FanEQ Control
Press Enter
Press Enter
μGuru Utility v1.00C
ABIT EQ
1st FanEQ Group
Enabled
CPU Temperature
65°C/149°F
35°C/95°F
100 %
30 %
Enabled
SYS Temperature
40°C/104°F
30°C/86°F
12.0 V
8.0 V
Enabled
SYS Temperature
40°C/104°F
30°C/86°F
12.0 V
8.0 V
Item Help ►►
F10:Save ESC:Exit
Item Help ►►►
F10:Save ESC:Exit
2-9
