HARDWARE CONTENTS (SHOWN ACTUAL SIzE)
AA BB
M5 x 2 mm
M5 x 2 mm
Slide Screw
Truss Screw
Qty. 6
Qty. 3

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and diagram
above. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts.
For Easiest Assembly:
• To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks or
openings.
• Clear an area large enough to layout all components and hardware.
• When applicable, tighten all hardware connections by hand first. Once the step is completed go back and fully tighten all
hardware.
• Follow all steps in order to properly assemble your product.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (Included):
No. 2 Phillips Head Screwdriver
CC DD
M5 x 2 mm
Flat Screw
Qty. 4
M5 x 62 mm
Screw
Qty. 2
M8 Wrench
EE FF
M8 Nut
Qty. 2
M5 Wing Nut
Qty. 5
5
GG HH
6 mm Heat
Resistant
Washer
Qty. 4
M6 Wing Nut
Qty. 4
