3. OPERATING DETERMINATIONS

If this equipment is operated in any other way, than
those described in this manual, the product may
suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-
circuit, burns, electric shocks, lamp failures, etc.
Do not endanger your own safety and the safety
of others. Incorrect installation or use can cause
serious damage to people and property.

Function setting

Status Value
A001-A512 001-512
A1_ (1-9)
A2_ (1-9)
A3_ (1-9)
A__
A4_ (1-9)
A5_ (1-9)
A6_ (1-9)
A7_ (1-9)
S1_ S1_ (1-20)
S2_ S2_ (1-20)
S3_ S3_ (1-20)
Flash F_(1~11)
DMX A001~512
SLAV
SA_ SA_(01~09)
Function setting
Channel Value
CH1 0-255
CH2 0-255
CH3 0-255
P. 4
Tecshow Derby Lite | English version
DMX mode
Red + Orange + Blue always on slow to fast
Yellow + White + Amber bengal always on slow to fast
Green + Purple + Rose always on slow to fast
One or three or all groups color are on. Slow to fast
One or six or all groups color are on. Slow to fast
one or seven or all groups color are on by gradual change. Slow to fast
one or eight or all groups color are on by gradual change. Slow to fast
In sound, color change, blasting flash mode
Sound, color change, the dynamic model
Sound, color change, lyrical mode
Automatic flash explosion, through the key - + key blasting flash speed
can by adjusted
Through the key into, change numerical value by up and down
Slave mode
Sound sensitivity
Dimmer 0-100%
Red + Orange dimmer, from 0-100%
Green + Purple dimmer, from 0-100%

Display panel operation

Turn On the light, then press Menu button. Enter
the main menu. Press button Up & Down to select
submenu. Press Enter button to confirm the value.
