kg/liter).
For Granita the bases are to be diluted with water on a 1
plus 4/4.5 basis.
For soft drinks the bases are to be diluted with more water,
on a 1 plus 5/5.5 basis.
In any case follow the syrup manufacturer's instructions for
both Granita and soft drink recipes.
If natural juices (e.g. lemon, orange) as well as sugarless
products (e.g. coffee) are used, dissolve 5.3 - 7 oz. of
sugar per 0.25 gallons.
IMPORTANT
However Granita mix may be done, its Brix (sugar
percent content) must be at least 13.
5 - Install the covers and check that they are correctly placed
over the bowls. The dispenser must always run with the
covers installed to prevent a possible contamination of the
product.
6 - Set the control switches

5.1 DESCRIPTION OF CONTROLS.

7 - Always leave the dispenser on, as the refrigeration stops
automatically when Granita reaches the proper thickness.
The mixers will continue to turn.
5. 1 DESCRIPTION OF CONTROLS
The dispenser is equipped with a power switch and a light
switch. In addition each bowl is individually operated by a
mixer/refrigeration switch. In fact it is possible to dispense both
soft drinks and Granita.
When a bowl is in Soft Drink mode the beverage temperature
is controlled by the corresponding thermostat.
When a bowl is in Granita mode the mix viscosity is controlled
by the corresponding adjustment screw located in the rear wall
of each container (for temperature and viscosity setting make
reference to chapter 5.2 OPERATION HELPFUL HINTS).
All the switches are located on the faucet side of the dispenser
in switch panels protected by switch covers (see figure 1).
With reference to figure 3 dispenser controls functions are as
as shown in chapter
figure 1
follows:
Power switch (A)
0 position : power is turned OFF to all functions.
I position : power is turned ON to all functions
and the other switches are enabled.
The fan motor runs.
Light switch (E)
0 position : all top cover lights are OFF.
I position : all top cover lights are ON, provided
that power switch (A) is set to I.
Mixer/refrigeration switch (B)
I position : mixer and refrigeration ON.
SOFT DRINK mode.
0 position : OFF.
II position : mixer and refrigeration ON.
GRANITA mode.
Thermostat (D)
Turn clockwise
Turn counterclockwise
To operate the unit:
1 - Set the power switch to I position.
2 - Set the mixer/refrigeration switches as follows:
- to the I position to get soft drink.
- to the II position to get Granita.
3 - Set the light switch to I position.

5. 2 OPERATION HELPFUL HINTS

1 - Granita viscosity adjustment: proper Granita viscosity is
factory preset. To change the viscosity, if needed, use a
standard screwdriver to turn the adjustment screw located
in the rear wall of each container as follows (see figure 3):
- towards right (clockwise) to obtain a thicker product (the
indicator F will go down in opening G).
- towards left (counterclockwise) to obtain a thinner
product (the indicator F will go up in opening G).
MT UL
figure 2
: to decrease temperature
: to increase temperature
