3. Install and tighten the handle knobs that you removed
in step 1 (Figure 3).
4. Move the handle to the operating position.
2

Filling the Engine with Oil

No Parts Required
Procedure
Note: Your machine does not come with oil in the engine,
but it does come with a bottle of oil.
Max. fill: 0.53 L (18 oz), type: SAE 30 detergent oil with an
API service classification of SF, SG, SH, SJ, SL, or higher.
1. Remove the dipstick
1. Dipstick
2. Slowly pour oil into the oil-fill tube until the oil level
reaches the Full line on the dipstick
overfill.
3. Install the dipstick securely.
(Figure 4).
Figure 4
(Figure 4). Do not
3

Charging the Battery

No Parts Required
Procedure
Electric-Start Model Only
Refer to Charging the Battery (page
4

Assembling the Grass Bag

No Parts Required
Procedure
1. Slip the grass bag over the frame as shown in
1
2
1. Handle
2. Frame
Note: Do not slip the bag over the handle
2. Hook the bottom channel of the bag onto the bottom
of the frame (Figure
5
16).
g027257
3
Figure 5
3. Grass bag
(Figure
6).
Figure 5.
5).
