CONTROLS AND FUNCTION
1. OPEN/CLOSE button: Press to load or eject the
disc. Each press will open or close the disc tray
on the transport. NOTE: If the tray will not open
when the disc is playing, first press the
PLAY/PAUSE button.
2. SEARCH mode button: Press this button to
toggle the function of the JOG WHEEL between
fast search mode (the yellow LED is lit) and
normal mode. The fast search function is
automatically turned off when the JOG WHEEL is
not used for more than 10 seconds.
PLAY MODE: normally the JOG WHEEL is used
as pitch bend tool to synchronize the beats of the
playing track to another track. When the fast search
mode is turned on, you can use the JOG WHEEL
to search very quickly forward /backward inside
the current track.
PAUSE MODE: normally the JOG WHEEL is used
to search very precisely (1 frame precision) for the
exact cue point. When the fast search mode is
turned on, you can use the JOG WHEEL to search
very quickly forward/backward inside the current
track.
3. LCD display: Shows all-important information
needed during playback. Refer to the next
chapter for more information.
4. PITCH slider: This slider is used to adjust the
playback pitch percentage when the PITCH
function is activated. The slider is a set
adjustment and will remain set until the pitch
slider is moved or the PITCH function has been
turned off. The maximum pitch range of the slider
is +/-16%. This adjustment can be made with or
without a CD in the drive. The pitch adjustment
will remain even if a disc has been removed, and
will reflect on any other disc loaded into the unit.
That is to say, if you set a +2% pitch on one disc,
remove that disc and insert another, that disc will
also have a +2% pitch. The amount of pitch being
3
1 2
8
9 10 11 12
4 5
13 14 15
20
applied will be displayed in the LCD. Use this
slider to match the BPM's of this unit to that of
another music source. By changing the pitch of
one disc with respect to the other in this way, the
beats can be matched.
5. RELAY button: When you switch the Relay
function on, alternately a track will be played from
both CDs until the relay function is disengaged.
You can always put a new CD in the player that
is waiting in standby mode. In this way you can
create an endless program. Perfect for use in
pubs etc.
6. SGL/CTN button: You can choose between
"single track mode" and "continuous play".
Continuous play: the complete CD will be played
without interruption. (mostly used in pubs)
Single track: player stops at the end of each
track and waits at the beginning of the next
track. (mostly used by deejays) Push the SGL/
CTN button for more than 1 second to switch
between normal and "auto cue" mode. In "auto
cue" mode the player waits at the first music
note of each track. This means that badly
indexed CDs will not interfere with the instant
start capabilities of this CD player. This is a
very useful feature for deejays!
7. TIME button: The TIME button switches between
elapsed playing time, remaining time in a selection
and total remaining time of the disc. (standard
=remaining / track)
8. JOG WHEEL: This jog wheel serves 4 functions
depending on the mode you are working in.
The jog wheel acts as a slow frame search (1/75
sec) control when the CD is not playing but either
paused or set to a cue point. To set a new cue
point, spin the wheel then press PLAY or IN
when you have determined the proper position.
Press CUE to return to the "CUE POINT".
4

Control unit

6 7
17 18 19
16
21
