Quick Start Guide
1.6

Inputs and outputs

A, B... Oscilloscope analog inputs. Refer to
maximum input voltage marked on front
panel of oscilloscope. [BNC(f)]
D0–D15. MSO logic inputs. Refer to
maximum input voltage marked on front
panel of oscilloscope. Refer to User's Guide
for pinout if not using the supplied cable. [20-
way header]
AWG or Gen. Signal generator or arbitrary
waveform generator output. Do not apply an
external voltage to this output. [BNC(f)]
Note: PicoScope 5000D Series 4-channel models are shown here. Other models may have a
different arrangement of connectors. Refer to your oscilloscope's data sheet for details.
DO115-20
Earth terminal. [M4 screw]
USB 3.0 connection to PC [USB 3.0
Type-B socket]. Some models have USB 2.0.
Power supply input as described
in Section 1.2.4. [2.1 mm barrel jack, center
positive]
Ext. External trigger input (some models).
[BNC(f)]
Copyright © 2006–2019 Pico Technology Ltd. All rights reserved.
1.7

Useful information

1.7.1 Free newsletter
Pico Technology sends out a free monthly newsletter by email. This gives news of product
launches, software upgrades and application notes, as well as hints and advice. We treat your
email address and other details as confidential and will not pass them on to any third party. To
subscribe, visit www.picotech.com/signuplibrary/newsletter.
1.7.2 Software updates and replacement
You can download the latest versions of all Pico software free of charge from
www.picotech.com/downloads. If you require a software disk, please contact Pico Technology
or your distributor.
1.7.3 Documentation
The Data Sheet contains the latest specifications for your PicoScope PC oscilloscope. We
recommend that you print a copy and keep it for easy reference.
You can download PDF copies of all documentation relevant to your oscilloscope, including the
User's Guide and Programmer's Guide, from www.picotech.com/downloads.
1.7.4 Writing your own software
PicoSDK, a software development kit with all the drivers and other files you will need to develop
your own custom programs, is available for download from www.picotech.com/downloads.
Pico also maintains repositories of examples for various programming languages at
github.com/picotech.
1.7.5 Technical support
Regularly updated technical support information can be found on the Pico Technology technical
support web page and users' forum at www.picotech.com/tech-support.
1.7.6 Warranty and returns
Your PicoScope USB oscilloscope device is supplied with a five-year return-to-
manufacturer warranty. All accessories are guaranteed for one year from the date
of purchase. You may also return your oscilloscope for any reason within 14 days of
purchase for a refund. For terms and conditions, visit www.picotech.com/about.
