Over-range: "OL" mark indication.
Low battery indication: A battery "
Measurement rate: 2 times per second nominal.
Auto power off: Meter automatically shuts down after approx. 30 minutes of
Operating environment: -10 o C to 50 o C (14 o F to 122 o F) at < 70 % relative
Storage temperature: -30 o C to 60 o C (-4 o F to 140 o F) at < 80 % relative
Relative humidity: 90% (0 o C to 30 o C); 75%(30 o C to 40 o C); 45%(40 o C to 50 o C);
For inside use, max height: Operating:3000m, Storage 10,000m
Pollution degree: 2
Safety: The instrument complies with IEC/EN 61010-1:2001 and IEC/EN
61010-031:2002
Power: One 9V battery , NEDA 1604, IEC 6F22.
Dimensions: 182 (H) x 82 (W) x55 (D) mm
Weight: Approx.: 375g.
Precisión: Accuracy is given at 18 o C to 28 o C (65 o F to 83 o F), less than 70 % RH
DC Voltage (Auto-ranging)
Range Resolution
400.0mV 0.1mV
4.000V 1mV
40.00V 10mV
400.0V 100mV
1000V 1V
Input Impedance: 10MΩ.
Maximum Input: 1000V dc or 1000V ac rms.
AC Voltage (Auto-ranging)
Range Resolution
400.0mV 0.1mV
4.000V 1mV
40.00V 10mV
400.0V 100mV
1000V 1V
All AC voltage ranges are specified from 5% of range to 100% of range
Input Impedance: 10MΩ.
©Copyright Abacanto Digital SA.
voltage drops below the operating level.
inactivity.
humidity.
humidity.to
Remarks
+0.8% of rdg + 2 digits
+1.0% of rdg + 2 digits
Remarks
+1.0%of rdg + 3 digits
+1.2%of rdg + 5 digits
Manual de usuario AD-9962
AD Instruments
"symbol is displayed when the battery
