Pulsar LEXION Instruciones De Operacion página 4

MODEL Lexion XP28
SKU#
77443
Microbolometer:
Type uncooled
Resolution, pixels 640x480
50
Frame rate, Hz
Pixel size, µm 17
Optical characteristics:
1.4
Magnification, x
1.4-11.2
Continuous digital zoom, x
2x/4x/8x
Digital zoom
F28 mm,
Objective lens
F/1.2
Field of view (horizont.),
degrees / m@100m 22 / 39
Dioptre adjustment, D ±5
Detection distance
(1,7 m object), m / y
1000 / 1094
Display:
Type
AMOLED
Resolution, pixels 640x480
Operational characteristics:
Power supply 3 – 4.2 V
Battery type / Capacity /
Output voltage
External power supply 5 V (USB)
Operating time on battery pack
(at t=22°C), h*
10
Degree of protection, IP code
(IEC60529), with installed battery IPХ7
Operating temperature range
Dimensions, mm
207x58x58
inch 8.1x2.3x2.3
Weight (without battery), kg 0.4
oz 14.1
Video recorder
Video / photo resolution, pixel
640x480
Video / photo format .avi / .jpg
Built-in memory
16 Gb
Built-in memory capacity
Wi-Fi channel
Frequency 2.4 GHz
Line-of-sight reception range, m
15
Standard 802.11 b/g
* Actual operating time depends on the extent of using Wi-Fi and integrated video recorder.
1
XP38 XP50
77444 77445
uncooled uncooled
640x480 640x480
50 50
17 17
1.9 2.5
1.9-15.2 2.5-20
2x/4x/8x 2x/4x/8x
F38 mm, F50 mm,
F/1.2 F/1.2
16.3 / 28.6 12.4 / 21.8
±5 ±5
1350 / 1476 1800 / 1969
AMOLED AMOLED
640x480 640x480
3 – 4.2 V 3 – 4.2 V
Li-Ion Battery Pack IPS7 / 6400 mAh /
DC 3.7 V
5 V (USB) 5 V (USB)
10 10
IPХ7 IPХ7
-25 °С ... +50 °С / -13 °F ... 122 °F
207x58x58 217x58x58
8.1x2.3x2.3 8.5x2.3x2.3
0.45 0.5
15.9 17.6
640x480 640x480
.avi / .jpg .avi / .jpg
16 Gb 16 Gb
300 min video or ˃20 000 pictures
2.4 GHz 2.4 GHz
15 15
802.11 b/g
802.11 b/g
MODEL Lexion
SKU#
Microbolometer:
Type
Resolution, pixels
Frame rate, Hz
Pixel size, µm
Optical characteristics:
Magnification, x
Continuous digital zoom, x
Digital zoom
Objective lens
Field of view (horizont.),
degrees / m@100m
Dioptre adjustment, D
Detection distance
(1,7 m object), m / y
Display:
Type
Resolution, pixels
Operational characteristics:
Power supply
Battery type / Capacity /
Output voltage
External power supply
Operating time on battery pack
(at t=22°C), h*
Degree of protection, IP code
(IEC60529),with installed battery
Operating temperature range
Dimensions, mm
inch
Weight (without battery), kg
oz
Video recorder
Video / photo resolution, pixel
Video / photo format
Built-in memory
Built-in memory capacity
Wi-Fi channel
Frequency
Line-of-sight reception range, m
Standard 802.11 b/g
This product is subject to change in line with improvements to its design.
The latest edition of this user manual is available online at www.pulsar-vision.com
XQ38 XQ50
77441 77442
uncooled uncooled
384х288 384х288
50 50
17 17
4,1
3,1
3,1 – 12,4 4,1 – 16,4
2x/4x 2x/4x
F38 mm, F50 mm,
F/1.2 F/1.2
9,8 / 17,2 7,5 / 13
±5 ±5
1350 / 1476 1800 / 1969
AMOLED AMOLED
640x480 640x480
3 – 4.2 V 3 – 4.2 V
Li-Ion Battery Pack IPS7 / 6400 mAh /
DC 3.7 V
5 V (USB) 5 V (USB)
10 10
IPХ7 IPХ7
-25 °С ... +50 °С / -13 °F ... 122 °F
207x58x58 217x58x58
8.1x2.3x2.3 8.5x2.3x2.3
0.45 0.5
15.9 17.6
640x480 640x480
.avi / .jpg .avi / .jpg
16 Gb 16 Gb
300 min video or ˃20 000 pictures
2.4 GHz 2.4 GHz
15 15
802.11 b/g
802.11 b/g
