4. The screen will then display the data as
shown in Figure 5. After the waveform
and value become stable, the user can
read the information on the display
screen.
5. When the screen displays as shown
in Figure 5, press the Display Key to
change the display screen's orientation:
a. Press the Display Key once; the
display screen will rotate 180° and
display as shown in Figure 6.
b. Press the Display Key twice; the
screen will now display as shown in
Figure 7.
c. Press the Display Key three times;
the display screen will rotate 180°
and display as shown in Figure 8.
d. Press the Display Key four times;
the display screen will return to the
original screen as shown in Figure 5.
JBO2007-INS-LAB-RevD18
Figure 5
Figure 7
Figure 6
Figure 8
