Indication of hot functions
Switching operating modes ("Zoom", "Inversion"), brightness and
contrast adjustment are shown as large pop-up icons in the upper part of
the display within two seconds.
Other functions
Press the " "(3) button to activate 2x digital zoom. Icon
on the data panel.
Keep " "(3) button pressed for two seconds to activate colour
inversion (functions "Hot white" and "Hot black").
When function "White hot " is used, warm objects are represented in
shades of bright colour; "Black hot " represents objects in shades of
dark colour.
10
USE OF THE VIDEO OUT JACK
"Video out" jack (11) is designed to connect external recording devices
and to transmit video signal to monitors, TV sets etc.
Make sure that the unit is turned off.
Use the included video cable to connect a peripheral device to the
"Video out" jack (11).
Select a suitable video output standard - PAL or NTSC (refer to section 9
"MENU"). A peripheral device will show the image seen through the
scope.
11
ACCESSORIES
Using the Weaver mounting rail (11), you can attach various accessories
to the Quantum S scopes, such as:
Battery packs EPS3/EPS5 (SKU#79111/79112)
CVR640 video recorder (SKU#17044) and others.
The ¼" tripod mounts from both sides of the scope are designed to have
the scope installed on a tripod or have a hand strap (included) attached.
12

CARE AND MAINTENANCE

The thermal imaging scopes have IPX4 degree of protection (protected
against splash water) but they are not intended for submersion into
water.
Attempts to disassemble or repair the scope will void the
warranty!
Clean the scope's optical surfaces only if necessary, and use caution.
First, remove (by blowing with a blower brush or canned air) any dust or
sand particles. Then proceed to clean by using camera/lens cleaning
equipment approved for use with multicoated lenses. Do not pour the
solution directly onto the lens!
10
The scope can be used in operating temperatures ranging from
-25 °C to +50 °C. However, if it has been brought indoors from cold
temperatures, do not turn it on for three to four hours. This will prevent
external optical surfaces from fogging.
Always store the unit in its carrying case in a dry, well-ventilated space.
Remove the batteries if the scope is not going to be used for an
extended period (longer than one month).
appears
Batteries shall not be exposed to excessive heat such as sunshine, fire
or the like.
13
TROUBLESHOOTING
Listed below are some potential problems that may occur when using the
scope. Carry out the recommended checks and troubleshooting steps in
the order listed. Please note that the table does not list all of the possible
problems. If the problem experienced with the scope is not listed, or if the
suggested action meant to correct it does not resolve the problem,
please contact the manufacturer.
problem
The unit will
not turn on.
The unit does not operate
on external power
supply.
The image is blurry, with
vertical stripes and uneven
background.
The image is too dark.
possible cause corrective action
Batteries have been wrongly Reinstall the batteries observing
installed. polarity.
Oxidized contact points in the
Clean the battery compartment,
battery compartment due to focusing on the contacts.
"leaky" batteries or contact
points becoming exposed to
a chemically reactive solution.
The batteries are fully Install fresh batteries.
exhausted.
Make sure your power supply Charge the power supply
provides output voltage. (if required).
Make sure the central If it's necessary, unbend
pin of the external the pin to ensure electric contact.
power supply is intact.
Calibration is to be done.
Do the calibration according to section
8 "OPERATION"
The lowest brightness level Adjust brightness by rotating the
is set. controller (5).
