Now you can read the minimum/maximum CO
To reset, select "Reset min/max" and press the PTK.
Select >> NEXT >> and press the PTK to return to the
main menu.
CO2 Min 643PPM
CO2 Max 760PPM
=> Reset min/max
>> NEXT >>

13. Replace the fuse

If a short circuit occurs due to fan overload, the fuse will
blow. Even if the Clima Control does not operate at all,
in the worst case, this could indicate a blown fuse. The
fuse (8A or in case of the 14A version: 15A) must then be
replaced. To replace the fuse(s), go through the
following steps (the fuse holder is placed at the front of
the controller, to the left of the socket):
1. Press the black fuse holder slightly with a
screwdriver and turn it a quarter of a turn
counterclockwise.
2. Remove the fuse holder.
3. Remove the fuse.
4. Insert a new 8 or 15 amp fuse (depending on the
version of your Clima Control).
5. Reinstall the fuse holder in the housing of the Clima
Control.
6. Then press the fuse holder again with a screwdriver
and tighten it by turning it a quarter turn clockwise.
Your Clima Control is ready for use again.
If the fuse of the fan is defective, the Clima Control itself
and any connected devices (Sensor, Datalogger) will
continue to operate.
____________________________________________________________________________________________________________________________
TechGrow | Innovative Growing Solutions
levels.
