Parts List - PEERLESS Mounts D-FPF-320 Manual De Instalación

Before you begin, make sure all parts shown are included with your product.

Parts List

Description
AA wall plate
BB deep adapter bracket
CC shallow adapter bracket
DD #14 x 2.5" wood screw
EE concrete anchor
FF 4 mm allen wrench
Parts may appear slightly different than illustrated.
AA
M4 x 12 mm (4)
(504-9013)
M4 x 25 mm (4)
(504-1015)
M6 x 25 mm (4)
(520-1208)
.75" spacer (4)
(540-1059)
SF660
Part Number
Qty.
201-1503
1
201-1510
2
201-1511
2
5S1-015-C03
4
590-0320
4
560-1727
1
BB
Adapter Bracket Fasteners
M5 x 12 mm (4)
(520-1027)
M5 x 25 mm (4)
(520-9543)
.5" spacer (4)
(540-1057)
M8 x 16 mm (6)
(520-9257)
SF660-S
Part Number
201-4503
201-4510
201-4511
5S1-015-C03
590-0320
560-1727
CC
DD
FF
M6 x 12 mm (4)
(520-1128)
M8 x 40 mm (4)
(520-1136)
3 of 34
SWS410/BK
RTFPF-320I
RTFPF-320
D-FPF-320
SF660P
Part Number
201-1503
201-1513
201-1514
5S1-015-C03
590-0320
560-1727
EE
M6 x 20 mm (4)
(520-9402)
multi-washer (4)
(580-1036)
ISSUED: 01-11-08 SHEET #: 202-9270-3 10-30-09
SWS410/SI
RTFPF-320SI
RTFPF-320S
D-FPF-320S
SF660P-S
Part Number
201-4503
201-4513
201-4514
5S1-015-C03
590-0320
560-1727
M6 x 30 mm (4)
(510-9109)
M8 x 25 mm (4)
(520-1031)
