Instructions for use

Product Compatibility and
Incubation programs
Bionova IC10/20FR Incubation Programs
®
The following incubation programs are available for your
Bionova IC10/20FR. Verify which incubation programs are
®
available for your country checking the Indications for Use
section.
Temperature
Time selection
selection
20 min (Ultra)
60 ºC
30 min
1 hs
2 hs
3 hs
PRO (15 min)
37 ºC 4 hs
To select the appropriate incubation program for the Indicator you
are planning to use, follow each Indicator's Instructions for use.
Select the appropriate incubation program before
the incubation of any Indicator.
Bionova IC10/20FR Auto-reader compatible indicators
®
We develop new Indicators for extending the features of
our incubators regularly. Please visit www.terragene.com/
compatible or scan the QR code below to check the latest
compatible Indicators developed for your incubator.

Serial/Batch Number

For easy identification, each Bionova
Incubator has a distinctive serial and batch numbers. The number
can be found printed on two labels, one placed at the bottom of
the Incubator, and one on its packaging. Please, register your
serial and batch numbers in this manual for future reference:
Serial Number:
Batch Number:
Incubation Program
20 min. at 60 °C
30 min. at 60 °C
1 hour at 60 °C
2 hours at 60 °C
3 hours at 60 °C
PRO at 60 °C
4 hours at 37 °C
IC10/20FR Auto-reader
®
IC10/20FR Page 7
Instructions for use

Start-up

1.Place the Bionova IC10/20FR Auto-reader Incubator
®
on a firm surface, free from vibrations, away from direct
sunlight, currents of hot or cold air, chemical and corrosive or
flammable substances. Do not place the Incubator in a way that
disconnection of the power supply's AC plug from mains could
be difficult. Leave a space of at least 10 cm from the Incubator
to the closest wall. Do not move the Incubator periodically or
during its use. Connect the Incubator to a secure and stable
electrical mains outlet socket.
Do not wet or heat the device. If liquid is spilled on the
Incubator, disconnect it and follow the instructions on
the Cleaning and maintenance section.
2.Power on your Bionova IC10/20FR by connecting the power
®
supply's AC plug to mains and then connect the plug at the
other end of power supply to the rear of the Incubator. The last
incubation program used (time and temperature combination)
will be selected by default.
Before power on, verify that all incubation
positions are empty.
If the Printer's paper indicator light starts blinking
after powering on the Incubator, check that the
printer's door is tightly closed and that the printer
has paper, if not follow the instructions on the
Replacement of the paper roll section.
3.Set the incubator internal clock to correspond to your local time.
See configuration methods in the Time setting mode section.
All devices are manufactured with the
following settings:
- Time zone: UTC +0:00
- Printing language: English
If you want to change the time zone, or the printing language
refer to Modification of time zone, or Modification of printing
language on the Set-up mode section.
4.Check that the incubation temperature is correct. To change
it, press the button for 3 seconds. Lights corresponding to
37 °C and 60 °C will start blinking, indicating that a temperature
program must be selected. For temperature selection, press the
button to select 37 ºC or 60 ºC. After 4 seconds the
temperature modification will be accepted.
For 37 ºC, the IC10/20FR auto-reader will automatically select the 4 hrs.
final reading program in both sides of the incubation area (1-6 and 7-12).
For 60 ºC, Instant/Ultra (20 min.), 30 min., 1, 2 or 3 hrs. program
can be selected. It's possible to select different programs for
each half or the same for both, depending on the indicator´s final
reading characteristics.
Check that the time setting is appropriate for the SCBIs to be
incubated in each zone.
To change the time program, press the button
correspondent zone as many times as needed to choose
of the
